ADSS 12 Core Fiber Optic Network Cable For Communication , Optical Fiber

Payment Terms:	T/T,L/C,WU
Special Groups:	Outdoor (1)
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: ADSS

Production Capacity: 10000000M/week

Delivery Date: 5-7days

Type: ADSS

Certification: CE

Core: 12

Means of Transport: Ocean,Land,Air

Packing: 4km/reel

Application: Telecommunications

Brand Name: TESO

Jacket: PE

1.ADSS 12 core fiber optic cable.
2.Fiber type:ITU G652D, Standard for SM optical fibers with 6 color
3. Maximum Span(m):200.

ADSS 12 Core Fiber Optic Network Cable For Communication , Optical Fiber

Quick Detail:

1.ADSS 12 core fiber optic cable.

2.Fiber type:ITU G652D, Standard for SM optical fibers with 6 color

3. Maximum Span(m):200.

4.Structured : FRP strength member+ optical fiber+ Filler+ PBT loose tube +Tube filling compound + water blocking material +cable filling compound +PE inner sheath+ Aramid yarn strength member+ PE outer sheath

Description

*ADSS optical cable adopts loose tube stranded.

*Optical fiber are positioned into a loose tube made of high modulus plastics.

* The tubes are filled with a Water-blocking filling compound.

*The tubes(and fillers) are stranded around FRP as a non-metallic central strength member into compact and circular cable core.

*The cable is completed with PE outer jacket.

Laying method

Self-support Aerial Installation

Parameter

Item	Value
Cable Structure	1+6
Fiber Count	12
Maximum Field Voltage(KV)	12
Fiber Type	ITU G652D, Standard for SM optical fibers with 6 color
Loose Tube	PBT Loose Tube with 6 fibers in each tube and 2 color: blue/orange
Ref. Outer Diameter ±0.2(mm)	12.1
Modulus of Elasticity(kN/mm2)	10.1
Attenuation Coefficient (db/km)	≤0.36@1310	≤0.22 @1550

Mechanical Behavior

Maximum Span(m)	200
Wind Speed(m/s)	40
Ref. Weight(Kg/km)	125
Heat Expansion Coefficient(10-6/oC)	5.5
Break Strength (KN) / RTS	12
Max. Tensile Strength(N)	Short Term:2200	Long Tern:1000
